Supports Intel® Core™ Ultra Processors (Series 2)(LGA1851).
16+1+1+1+1 Power Phase, Dr.MOS for VCore+GT.
4 x DDR5 DIMMs, Supports Dual Channel, up to 9066+ (OC).
1 PCIe 5.0 x16, 2 PCIe 4.0 x4, 1 PCIe 4.0 x1.
Graphics Output Options: 1 HDMI, 1 DisplayPort, 2 Thunderbolt™ 4 Type-C.
Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio.
4 SATA3
1 Blazing M.2 (PCIe Gen5x4), 2 Hyper M.2 (PCIe Gen4x4), 1 Hyper M.2 (PCIe Gen4x4 & SATA3).
2 Thunderbolt™ 4 Type-C (Rear), 1 USB 3.2 Gen2x2 Type-C (Front), 1 USB 3.2 Gen2 Type-A (Rear), 6 USB 3.2 Gen1 (2 Rear, 4 Front), 8 USB 2.0 (4 Rear, 4 Front).
Realtek 2.5G LAN.
802.11axe Wi-Fi 6E + Bluetooth.
Supports BIOS Flashback, Memory OC Shield, M.2 Bottom Heatsink.
Performance Gains from Intel 200S Boost
ASRock Z890 motherboards now support Intel 200S Boost through a simple BIOS update.Users can effectively "upgrade" their existing Intel Core Ultra processors and enjoy a significant performance boost.
Visit the ASRock official website to download the latest BIOS and experience the performance upgrade brought by Intel 200S Boost.
16+1+1+1+1 Power Phase Design
Featuring sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.
DDR5 XMP & EXPO Support
Derived from the “built for stable and reliable” designing concept, ASRock does not compromise on any details. This motherboard is built with high quality materials, enthusiasts are able to enjoy the boost of DDR5 memory overclocking performance by enabling the pre-tested profiles. Make sure the memory modules are Intel XMP/AMD EXPO™ capable and overclocking can be made so affordable, satisfying and absolutely no sweat at all.
Enlarged M.2 Heatsink
The extra large aluminum alloy M.2 heatsink effectively improves heat dissipation to keep those high speed M.2 SSDs as cool as possible, it is able to give better stability while maintaining top performance.
Wi-Fi 6E 802.11axe
WiFi 6E technology has extended to the whole new 6GHz spectrum band, providing more WiFi capability and giving an even better and faster internet traffic. In addition to deliver higher speeds, the WiFi 6E also enhances the lower latency and supports service levels that are equivalent to 5G networks.
Thunderbolt™ 4 Type-C
Thunderbolt™ 4 technology brings speed and versatility to the most advanced USB Type-C, offering a fast and simple level of connection for work or home. It enables lightning-fast data transfer up to 40Gbps and connects external monitors, Thunderbolt™, and USB devices with a single Thunderbolt 4 cable.
| Brand | ASRock |
| Color | Black-White |
| Model | Z890 PRO RS WIFI |
| Unique Features | |
| Superb Productivity | – PCIe Gen5 (Graphics, M.2) – Dual Channel DDR5 – Thunderbolt™ 4 Type-C Ports (40 Gb/s) |
| Rock-Solid Durability | – 16+1+1+1+1 Power Phase, Dr. MOS for VCore+GT with Enlarged Heatsink Armor – Memory OC Shield – Flexible Integrated I/O Shield |
| Ultrafast Connectivity | – 2.5G LAN, 802.11axe Wi-Fi 6E Module |
| EZ Update | – BIOS Flashback Button – ASRock Auto Driver Installer |
| EZ Troubleshooter | – ASRock Post Status Checker |
| CPU Support | |
| Socket | LGA1851RL-ILM |
| Processor Support | Intel® Core™ Ultra Processors (Series 2) |
| Technologies | – Intel® Hybrid Technology – Intel® Turbo Boost Max 3.0 – Intel® Thermal Velocity Boost (TVB) – Intel® Adaptive Boost Technology (ABT) – Integrated NPU for AI acceleration |
| Chipset | Intel® Z890 |
| Memory | |
| Type | Dual Channel DDR5 |
| Slots | 4 x DDR5 DIMM |
| Maximum Capacity | 256GB |
| Memory Support | – DDR5 non-ECC, un-buffered up to 9066MHz+(OC) – Supports CUDIMM – Intel® XMP 3.0 |
| Graphics | |
| Integrated Graphics | Intel® Xe LPG Graphics Architecture |
| Display Outputs | – HDMI 2.1 (4K 120Hz) – DisplayPort 1.4 (8K 60Hz / 5K 120Hz) – 2x Thunderbolt™ 4 (8K 60Hz / 5K 120Hz) |
| Storage | |
| M.2 Slots | – 1x PCIe Gen5x4 (128 Gb/s) – 2x PCIe Gen4x4 (64 Gb/s) – 1x SATA3/PCIe Gen4x4 |
| SATA | 4 x SATA3 6.0 Gb/s |
| RAID Support | RAID 0, 1, 5, 10 (both SATA and NVMe) |
| Networking | |
| LAN | 2.5 Gigabit LAN (Dragon RTL8125BG) |
| Wireless | – Wi-Fi 6E (802.11axe) – Bluetooth 5.3 |
| Audio | 7.1 CH HD Audio (Realtek ALC897) |
| USB Ports | |
| Rear | – 2x Thunderbolt™ 4 Type-C – 1x USB 3.2 Gen2 Type-A – 2x USB 3.2 Gen1 |- 4x USB 2.0 |
| Internal Headers | – 1x USB 3.2 Gen2x2 Type-C – 2x USB 3.2 Gen1 – 2x USB 2.0 |
| Form Factor | ATX (12.0-in x 9.6-in, 30.5 cm x 24.4 cm) |
| OS Support | Microsoft Windows® 11 64-bit |
| Warranty | 3 Years |
| Note | * Features, Price, Specifications are subject to change without notice. |
