High-performance cooling
Six patented superconductive composite heat pipes transfer heat quickly and evenly from the CPU for superior thermal performance, even under heavy loads.
Dual Mobius 120P PWM fans
Two pressure-optimized 120 mm PWM fans deliver high airflow and static pressure for efficient cooling with quiet operation.
Compact, build-friendly design
At just 159 mm in height and ~30 % smaller than its predecessor, it fits most mid-tower cases and clears tall memory modules.
Wide platform compatibility
Works out of the box with modern Intel sockets (including LGA 1851 & LGA 1700) and AMD sockets (AM5 & AM4), giving broad support for current builds.
Easy installation
Tool-free brackets, removable magnetic top cover and fans make setup faster and less frustrating.
Stealth aesthetic
Sleek black (or white) minimalist top cover enhances build visuals without RGB clutter.
Long-term reliability
Durable nickel-plated copper base and loop dynamic bearing fans backed by a 5-year warranty.
|
Brand |
Cooler Master |
|
Model |
MAP-T6PN-225PW-CW |
|
CPU Socket |
Intel® LGA 1851 / 1700 / 1200 / 1151 / 1150 / 1155 / 1156 |
|
|
AMD® AM5 / AM4 |
|
Color |
White |
|
Heat Sink Material |
6 Heat Pipes/ Aluminum Fins |
|
Fan |
Size (mm): 120 |
|
|
Profile: Non LED |
|
|
Quantity (pcs.): 2 |
|
|
Speed: 0 – 2400 RPM ± 10% |
|
|
Airflow (max.): 127.6 m3/h(75.2 CFM) |
|
|
Pressure (max.): 3.63 mmH2O |
|
|
MTTF: > 200,000 hours |
|
|
Noise Level(max.): 30 dBA |
|
|
Bearing: Loop Dynamic Bearing |
|
|
Power Connector: 4-Pin PWM |
|
|
Rated Voltage: 12 VDC |
|
|
Rated Current: 0.18 A |
|
|
Safety Current: 0.35 A |
|
|
Power Consumption: 2.16 W |
|
|
Dimension (L x W x H): 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch |
|
Dimension |
Product: 127 X 114 X 159 mm / 5.0 x 4.4 x 6.2 inch |
|
|
Box: 23 x 19 x 16.5 cm / 9.06 x 7.48 x 6.5 inch |
|
Weight |
Net: 1.35 kg / 2.98 lb |
|
|
Gross: 2.17 kg / 4.78 lb |
|
Warranty |
5 Years |
|
Note* |
Price, feature and specifications are subject to change without notice |
