Next-Gen NVIDIA Architecture
Powered by NVIDIA’s latest architecture (likely Ada Lovelace or newer), offering superior performance and efficiency
16GB GDDR6 Memory
Massive 16GB of high-speed GDDR6 VRAM for handling demanding games, creative tasks, and multitasking with ease.
Factory Overclocked (OC Edition)
Comes pre-overclocked for improved clock speeds and enhanced out-of-the-box performance.
Twin X2 Dual-Fan Cooling System
Advanced dual-fan design ensures efficient heat dissipation and quieter cooling under heavy load.
DLSS 3.0 Support
AI-powered Deep Learning Super Sampling boosts frame rates while maintaining sharp image quality.
Real-Time Ray Tracing
Enhanced ray tracing cores deliver lifelike lighting, shadows, and reflections for immersive gaming.
PCI Express 4.0 Interface
High-bandwidth interface for faster communication with the CPU and improved overall GPU performance.
Multi-Monitor Support
Features HDMI and DisplayPort outputs to support multiple displays and high refresh rate monitors.
DirectX 12 Ultimate & Vulkan API Ready
Supports the latest graphics APIs for advanced visual effects and game engine compatibility.
VR Ready
Optimized to deliver smooth virtual reality experiences with compatible VR headsets.
|
Brand |
Inno 3D |
|
Modal |
N506T2-16D7X-191073N |
|
Color |
Black |
|
GPU Engine Specs |
CUDA Cores: 4608 |
|
|
Base Clock: 2235 MHz |
|
|
Boost Clock (OC): up to 2602 MHz Ezpz SolutionsMD ComputersComputech Store |
|
Memory |
Capacity: 16 GB GDDR7 |
|
|
Memory Clock: 28 Gbps (effective) |
|
|
Bus Width: 128‑bit |
|
|
Bandwidth: 448 GB/s Ezpz SolutionsComputech Store |
|
Power & Thermal |
Typical Power Consumption (TDP): 180 W varietyinfotech.comComputech Store |
|
|
Recommended PSU: 650 W Ezpz SolutionsMD Computers |
|
|
Power Connector: 1×8‑pin Ezpz SolutionsMD Computers |
|
Architecture & API Support |
Architecture: NVIDIA Blackwell |
|
|
Ray Tracing: 4th Gen (72 TFLOPS) |
|
|
Tensor Cores: 5th Gen (759 AI TOPS) |
|
|
DLSS 4 (with Multi Frame Gen) |
|
|
DirectX 12 Ultimate, OpenGL 4.6, Vulkan 1.4 Computech Storevarietyinfotech.com |
|
Bus Interface |
PCI Express Gen 5 (x16) varietyinfotech.comComputech Store |
|
Display Support |
Outputs: 3× DisplayPort 2.1b, 1× HDMI 2.1b |
|
|
Max Digital Resolution: up to 4K @480 Hz or 8K @165 Hz (with DSC) |
|
|
Multi‑Monitor: Up to 4 displays |
|
|
HDCP 2.3 Ezpz SolutionsComputech Store |
|
Cooling & Design |
Twin X2 Dual 88 mm scythe‑blade fans with Freeze Fan Stop |
|
|
Dual‑slot, small‑form‑factor‑friendly |
|
|
4× nickel‑plated composite heatpipes, copper GPU base, aluminum memory base, optimized heatsink with low‑noise fans, |
|
|
Metal multifunctional backplate (heat dissipation & PCB protection) Ezpz SolutionsMD Computers |
|
Dimensions & Form Factor |
Length: 250 mm |
|
|
Height: 116 mm |
|
|
Width: 41 mm |
|
|
Slot Size: Dual‑slot Ezpz SolutionsComputech Store |
|
Software & Features |
NVIDIA Studio & Broadcast Technologies |
|
|
DLSS 4, NVIDIA Ansel, FreeStyle |
|
|
NVIDIA ShadowPlay, GPU Boost, Game Ready & Studio Drivers, G‑SYNC‑Ready, NVIDIA Highlights, NVENC (9th gen) & NVDEC (6th gen) Computech StoreEzpz Solutions |
|
Compatibility |
OS: Windows 10/11, Linux, FreeBSDx86 Ezpz SolutionsArcis Power |
|
Release & Product Code |
Product Model No: N506T2‑16D7X‑193075N |
|
|
Release: Mid‑2025 (launched April 16, 2025) |
|
Warranty |
3 Years |
|
Note |
Price, Feature and Specifications Are Subject To Change Without Notice. |
