HUGE SPEED BOOST
Get random read/write speeds that are 40%/55% faster than 980 PRO; Experience up to 1400K/1550K IOPS, while sequential read/write speeds up to 7,450/6,900 MB/s reach near the max performance of PCIe 4.0
BREAKTHROUGH POWER EFFICIENCY
Use less power and get more performance; Enjoy up to 50% improved performance per watt over 980 PRO, plus optimal power efficiency with max PCIe 4.0 performance
SMART THERMAL CONTROL
Samsung's own nickel-coated controller delivers effective thermal control; With its slim size, 990 PRO is a perfect fit for desktops and laptops that meet the PCI-SIG D8 standard
THE CHAMPION MAKER
Up to 65% improvement in random performance enables faster loads for an ultimate gaming experience on PS5 and DirectStorage PC games
SAMSUNG MAGICIAN SOFTWARE
Get the most out of your SSD with Samsung Magician's advanced yet intuitive optimization tools; Monitor drive health, protect valuable data, and receive important updates for your 990 PRO
|
Brand |
Samsung |
|
Model |
MZ-V9P1T0BW |
|
General Feature |
|
|
Application |
Client PCs, Game Consoles |
|
Capacity |
1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
|
Form Factor |
M.2 (2280) |
|
Interface |
PCIe Gen 4.0 x4, NVMe 2.0 |
|
Dimension |
80 x 22 x 2.3 mm |
|
Weight |
Max 9.0g Weight |
|
Storage Memory |
Samsung V-NAND 3-bit MLC |
|
Controller |
Samsung in-house Controller |
|
Cache Memory |
Samsung 1GB Low Power DDR4 SDRAM |
|
Special Feature |
|
|
TRIM Support |
Supported |
|
S.M.A.R.T Support |
Supported |
|
GC (Garbage Collection) |
Auto Garbage Collection Algorithm |
|
Encryption Support |
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
|
WWN Support |
Not supported |
|
Device Sleep Mode Support |
Yes |
|
Performance |
|
|
Sequential Read |
Up to 7,450 MB/s * Performance may vary based on system hardware & configuration |
|
Sequential Write |
Up to 6,900 MB/s * Performance may vary based on system hardware & configuration |
|
Ramdom Read (4KB, QD32) |
Up to 1,200,000 IOPS * Performance may vary based on system hardware & configuration |
|
Ramdom Write (4KB, QD32) |
Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration |
|
Ramdom Read (4KB, QD1) |
Up to 22,000 IOPS * Performance may vary based on system hardware & configuration |
|
Ramdom Write (4KB, QD1) |
Up to 80,000 IOPS * Performance may vary based on system hardware & configuration |
|
Environment |
|
|
Average Power Consumption |
*Average: 5.4 W*Maximum: 7.8 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration |
|
Power Consumption (idle) |
Max. 50 mW * Actual power consumption may vary depending on system hardware & configuration |
|
Allowable Voltage |
3.3 V ± 5 % Allowable voltage |
|
Reliability |
1.5 Million Hours Reliability (MTBF) |
|
Operating Temperature |
0 – 70 ℃ Operating Temperature |
|
Shock |
1,500 G & 0.5 ms (Half sine) |
|
Warranty |
5-Year Limited Warranty or 600 TBW Limited Warranty |
|
Note** |
**Prices, Specifications & Features are subject to change without notice |
