Power Evolved
Cooler Master presents the MWE Bronze V3 230V, the upgraded version of the MWE Bronze featuring ATX 3.1 support, high temperature resilience, a smart DC-to-DC + LLC circuit design, a quiet HDB fan, 80 Plus Bronze efficiency, an embossed cable, and a 5-year warranty.
ATX 3.1 Support
Compliant with ATX 3.1 to fully support a peak power 1.5 times higher than the rated maximum wattage, this unit is ideal for use with the 40 series GPUs.
Embossed Cable
An embossed cable texture provides a softer and overall improved grip with a pleasing aesthetic.
Quiet HDB Fan
A hydrodynamic bearing fan delivers long-lasting quiet and effective cooling.
Certified Efficiency
The MWE Bronze V3 230V is certified to achieve more than 88% efficiency at typical loads.
High Temperature Resilience
A 40°C operating temperature allows for pushing your machine to the limits.
|
BRAND |
COOLER MASTER |
|
MODEL |
MPE-6501-ACABW-3BIN |
|
COLOR |
BLACK |
|
ATX VERSION |
ATX 12V V3.1 |
|
PFC |
ACTIVE PFC |
|
INPUT VOLTAGE |
200-240VAC |
|
INPUT CURRENT |
5A |
|
INPUT FREQUENCY |
50-60HZ |
|
DIMENSIONS (L X W X H) |
140 X 150 X 86 MM |
|
FAN SIZE |
120MM |
|
FAN BEARING |
HDB |
|
FAN SPEED |
2400 RPM |
|
NOISE LEVEL @ 20% |
16.54 DBA |
|
NOISE LEVEL @ 50% |
26.5 DBA |
|
NOISE LEVEL @ 100% |
42.5 DBA |
|
EFFICIENCY |
>88% TYPICALLY |
|
80 PLUS RATING |
80 PLUS BRONZE EU 230V |
|
ERP 2014 LOT 3 |
YES |
|
POWER GOOD SIGNAL |
100 – 150 MS |
|
HOLD UP TIME |
>16MS |
|
MTBF |
>100,000 HOURS |
|
PROTECTIONS |
OVP, OPP, SCP, UVP, OTP |
|
REGULATORY |
TUE, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC(based on regioN’S request.) |
|
ATX 24 PIN CONNECTORS |
1 |
|
EPS 4+4 PIN CONNECTORS |
2 |
|
EPS 8 PIN CONNECTOR |
1 |
|
SATA CONNECTORS |
6 |
|
PERIPHERAL 4 PIN CONNECTORS |
3 |
|
PCI-E 6+2 PIN CONNECTORS |
4 |
|
SERIES |
MWE BRONZE SERIES |
|
80 PLUS |
BRONZE |
|
MODULAR |
NON MODULAR |
|
WATTAGE |
500 TO 750W |
|
WARRANTY |
5 years |
|
NOTE |
*Features, Price and Specifications are subject to change without notice. |
